    Portable Thermal Vision Scope , Image Thermal Monocular For Hunting

    Ask Lasest Price
    Brand Name : KEEPGUARD
    Model Number : KG510IR
    Certification : FCC CE ROHS
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 PCS PER WEEK
    Delivery Time : 3-7 DAYS
    • Product Details
    • Company Profile

    Portable Thermal Vision Scope , Image Thermal Monocular For Hunting

    Portable Thermal Vision Scope , Image Thermal Monocular For Hunting


    Thermal Vision Scope Features


    · Small size, one hand operation

    · Live transmission via WIFI, APP real-time browsing, recording, photographing, playback and other operations on smartphone

    · IP66 protection, one meter drop resistance

    · Hot-spot tracking function support

    · Built-in multiple color palettes and crosshair indicator


    Thermal Vision Scope Introduce


    It's time to upgrade your KG510lR series. Connectedto mobile APP via Wi-Fi, the new KG510lR series canbe remote controlled to display synchronously, take photos and videos. Compared with the last version, it provides superior image, longer detection range andadvanced algorithm, helping to pick up the targets.


    Thermal Vision Scope Application


    Hunting /Law enforcement/Outdoor /Patrol/
    Search & Rescue/Personal Security


    Thermal Vision Scope Parameters


    ItemKG510IR N1KG510IR N1 WIFIKG510IR N2KG510IR N2 WIFI
    Detector
    Detector Type400 ×300@17 μm
    Spectral Range8μm~14 μm
    Lens
    Focus19mm25mm
    FocusingfreeManual
    FOV19.0°×14.5°14.6°×11.1°
    ScreenColorful 0.2″LCOS
    ViewfinderMonocular, diopter adjustable±4
    Frame50Hz
    Digital Zoom×2, ×4
    Color PaletteBlack hot, white hot, red hot 1, red hot 2, red hot 3
    Fuctions
    Photograph××××
    Additional functionsIlluminator or laser
    pointer or neither
    Illuminator or laser
    pointer or neither
    Illuminator or laser
    pointer or neither
    Illuminator or laser
    pointer or neither
    Cross cursor
    Image enhancement××
    Wi -Fi××
    Zoom
    Freeze××
    Charging indicator
    Active indicator×
    Power
    BatteryInternal Li -ion battery,3.7V,3200mAh
    Working Time≥5h
    AdapterStandard USB power adapter, max 10W
    Interface
    USBCharging
    Video OutputMCX Connector,PAL /NTSC
    Environment Characteristics
    Working Temperature-10℃~50℃
    Storage Temperature-30℃~60℃
    Humidity10%~95%
    Shock10Hz~150Hz~10Hz 0.15mm IEC60068 -2-6
    EncapsulationIP66
    Drop1m dropN/A
    Physical Parameter
    Weight350g375g
    Size160mm ×67mm ×62mm168mm ×67mm ×62mm
    Package
    Standard accessoriesthermal imager/ power adapter/ USB cable/ video cable /lens cap/ wrist strap/shoulder strap/ soft drawstring bag/ user manual
    Optional accessoriesN/A40mm extender lens (FOV:9.3°×7.0°)
    Detection Range
    Human :1.8m ×0.5m500m700m
    Vehicle:2.3m ×2.3m1300m1700m
    Recognition Range
    Human :1.8m ×0.5m300m350m
    Vehicle:2.3m ×2.3m500m700m
