LCD Display 12MP 8M 3M Digital Wildlife Camera

INTRODUCTION

This KEEPGUARD CAM is the best-selling scouting camera which is designed for activity and is resistant against water and snow. It is equipped with built-in infrared LEDs, so that it can be triggered by any movement in a location, then take high quality pictures or video clips.

Loading Batteries

After opening the two latches on the right side of the camera, you will see that it has 8 battery slots. For maximum battery life, we recommend using 8 lithium AA or alkaline AA batteries.

Using an External Power Source

Optionally, you can connect an external 6V DC power source to the "DC In" jack at the bottom of camera. It is recommended to use a power source with a current output greater than 1000mA. Please make sure that the polarity is correct.

Inserting SD Card

This camera have 32MB internal memory, which is for camera upgrade. Insert the SD card ( OFF mode ) before beginning to operate the camera. SD card is supported up to maximum 32GB capacity.

Formatting the SD card:

Formatting the SD card removes all files on the memory card and prepares for camera. Press the MENU, then RIGHT or LEFT key several more times to move to the “Format” parameter setting menu. Press OK key to enter sub-menu, Press the UP or DOWN key to highlight YES and press OK.

THE OFF, ON, and SETUP MODES

The KEEPGUARD CAM has three basic operational modes:

OFF Mode

The OFF mode is the "safe" mode when any actions must be taken, e.g. replacing the SD card or batteries, or transporting the device. You will use OFF mode if you connect the camera to a computer′s USB port to download your photos/videos.

ON Mode

Once in ON mode no manual controls are needed or possible (the control keys have no effect). The KEEPGUARD CAM will take photos or videos automatically (according to its current parameter settings) when it is triggered by the PIR sensor′s detection of activity in the area it covers.

SETUP Mode

In the SETUP mode you can check and change the settings of the KEEPGUARD CAM with the help of built-in LCD. Moving the power switch to the SETUP position will turn on the LCD display and you will see an information screen.

KG691 SPECIFICATIONS

Pictures

Keepway  Industrial ( ASIA ) CO.,LTD set up in 2003, is a coalition of independent development of hardware and software, industrial design, mold stamping, SMD assembly together, focusing on sales of digital video products and consumer electronics. The most experienced and technological innovation capability of enterprises, we mainly undertake hunting cameras, bird-watching cameras, garden cameras, sports Bluetooth headset, night vision, traps and other products of the hardware and software development, production and after-sales service.

Since its inception, the enterprise has been in a rapid and healthy development track, and has set up Hong Kong office as a market development and sales operations center and Shen Zhen Office as a research and development production center. We have more than 6,000 square meters of manufacturing plants and more than 1,000 square meters of research and development management center.

After more than 16 years of development, all have achieved good results. The formation of a unity and pragmatic, pioneering and innovative R&D and marketing teams makes our products exported to more than 20 countries in Europe and the United States. Especially in product software development, wireless technology, image algorithms, lens design, night vision technology, we have a major breakthrough. In the professional technical knowledge and advanced innovative ideas, we have successfully developed a variety of high-end consumer digital products. And through continuous innovation, company access to dozens of patents, in 2014 successfully achieved a national high-tech enterprises eligible.

Enterprises will be adhering to the "integrity, quality, win-win" principle, and establish long-term good partnership with customers around the world, joining hands in creating a better future.

Our advantages:
1, professional, focused, more selective.
2, a leading research and development team, guaranteed quality, good service.
3, internal process reaction speed is fast, staff cohesion is strong.

We have 21 years of OEM/ODM expertise and receive OEM/ODM order,Welcome!
